Product Details:
|
| Product Name: | Food Powder Grinder Pin Mill Pulverizer Grinding Milling Machine | Material: | SS 304/316 |
|---|---|---|---|
| Application: | Food, Chemical, Medical,etc | Capacity: | 50-1000 Kg/h |
| Fineness: | 40-1000 Mesh | Feed Size: | <15 Mm |
| Voltage: | Customized | Warranty: | One Year |
| Highlight: | pin mill grinding machine,plantain grinder machine |
||
Industry grain powder pin mill machine rice wheat flour milling machine with CE
BSZ pin mill is mainly applicable to the crushing processing of crystalline materials from chemical industry, dyestuff, auxiliaries, feed, food, medicine, and non-metal minerals. It has the advantages of high output, fine particle size, low noise, low energy consumption, simple maintenance and easy installation.
Working method:
After materials are sent to the crushing chamber through the screw conveyor from the hopper, they will be impacted, cut and grinded and crushed by high-speed rotating blades (needle bar types) and fixed needle bar disks. The powder is discharged outside the cavity through a screen and the particle size can be obtained by replacing the screen mesh of different pore sizes. It is mainly applicable to the crushing processing of crystalline materials from chemical industry, dyestuff, auxiliaries, feed, food, medicine, and non-metal minerals. It has the advantages of high output, fine particle size, low noise, low energy consumption, simple maintenance and easy installation.
Main features:
1. Specialized in milling for various fruit,walnuts,coffee beans,cocoa beans,peanuts,rice and other food and chemical raw material.
2. Pin mill for spices machine is alse used for grinding food,chemicals and the efficiency is very good.
3. The machine is table size so it is easy to install.
4. Change the powder particle size by changing the speed of inverter.
Our company:
Brightsail Machinery is the professional manufacturer Specially engages in various food,chemical, pharmaceutical machinery. Our factory developed about twenty types of machine in over seven varieties including Pulverizer ,Packing Machine, Dryer, Mixer, Cleaning and Peeling machine, Slicer cutter, Filling Machine and etc.
We have professional export office and professional engineer team. They will serve in the whole business. Same time after sales serve team can serve it if customer need on place. The world must become more better through our work hard together.
Most of machines are produced in our own factory ,thus we can offer you the best price and best technical service at the same time . we committed to providing high quality merchandise with good price.
Technical data:
| Model | BSZ-350 | BSZ-450 | BSZ-550 |
| Capacity(kg/h) | 60-200 | 150-500 | 230-700 |
| Feed size(mm) | <15 | <15 | <15 |
| Output size(mesh) | 40-1000 | 40-1000 | 40-1000 |
| Cavity disc crush motor(kw) | 18.5 | 22 | 37 |
| Door disc crush motor(kw) | 15 | 18.5 | 30 |
| Feed screw motor(kw) | 0.37 | 0.55 | 0.75 |
| Speed(rpm) | 12000 | 9600 | 8400 |
