Product Details:
|
| Total Volume (L): | 50-600 | Product Name: | Detergent Powder Granulator |
|---|---|---|---|
| Working Volume (L): | 12-400 | Stirrer Speed (R.P.M): | 20-200 |
| Mixing Power (KW): | 5.5-30 | Cutting Knife Speed(R.P.M): | 50-3000 |
| Other Name: | Rapid Mixer Granulator | Advantage: | Wide Application |
| Highlight: | Detergent Powder Blender Machine,10 Mins/Batch Powder Blender Machine,600L Powder Blender Machine |
||
Granulating Speed About 7 To 14 Mins Per Batch Wide Application Detergent Powder Granulator
The high-efficiency Mix Granulator is a special equipment for wet mixing and granulation of powder, starch, and adhesive in the production of tablets in the pharmaceutical industry. It is also suitable for mixing and granulating powdered materials in food and chemical industries.
Working Method Of Detergent Powder Granulator:
Technical Data Of Detergent Powder Granulator:
| Model | BSSF-50 | BSSF-100 | BSSF-200 | BSSF-300 | BSSF-400 | BSSF-600 |
| Total volume (L) | 50 | 100 | 200 | 300 | 400 | 600 |
| Working volume (L) | 12-36 | 25-70 | 50-150 | 60-220 | 100-280 | 150-400 |
|
Feeding quantity (kg) The specific gravity of the powder is 0.5g/cm³ |
6-18
|
12-35 | 25-75 | 30-110 | 50-140 | 75-200 |
| Stirrer speed (R.P.M) | 50-500 | 30-360 | 30-260 | 20-200 | 20-200 | 20-200 |
| Mixing power (KW) | 5.5 | 7.5 | 15 | 22 | 22 | 30 |
| Cutting knife speed(R.P.M) | 50-3000 | |||||
| Cutting power (KW) | 1.5 | 3 | 4 | 7.5 | 7.5 | 11 |
Features Of Detergent Powder Granulator:
1.The main barrel adopts a cylindrical and conical tangent structure, which is helpful for the tumbling of the material, and the geometric angle of the stirring paddle and the pelletizing knife is designed reasonably to ensure the best effect of mixing and granulating.
2.PLC control man-machine interface, automatic adjustment control according to program, high degree of automation, convenient operation.
3. Both the stirring blade and the cutting knife adopt frequency conversion speed regulation, and the speed can be adjusted arbitrarily, which can meet the granulation requirements of different varieties.
4.The whole process completes dry mixing and wet mixing granulation in the same closed container. Compared with the traditional process, the binder is reduced by 25%, and the drying time is shortened.
5. V-shaped pelletizing knife, there is no dead angle between the knife and the knife, which can improve the granulation rate and the rate of pellets.
FAQ:1) Q: How do you pack your machines?
A: If it's a small machine, it's packed in wooden cases.
If it is a large machine or many machines, we will take the container, we will split the machine into several parts, then wrap the machine with wrapping film, and then fix it in the container with wire rope to prevent them from shaking during transportation.
